    Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport

    Ask Lasest Price
    Brand Name : Star Trailer
    Model Number : SW-014
    Certification : ISO/CCC
    Price : Negotiable
    Payment Terms : L/C, D/A, T/T
    Supply Ability : 300 units per month
    Delivery Time : 40 days after receiving your payment
    • Product Details
    • Company Profile

    Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport

    Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
    Overview
    Quick Details

    Use:Truck Trailer Type:Semi-Trailer Material:Steel

    Certification:CCC/ISO Size:12400*2500*3650 OEM No.:Optional

    Max Payload:50T Brand Name:StarTrailer Model Number:Shuyue

    xle:FUWA 13 tons Brake:Wabco Floor thickness:3mm
    Supply Ability

    Supply Ability: 300 Unit/Units per Month 2 or 3 units packaged together to reduce the shipment cost.

    Packaging & Delivery

    Packaging Details

    Nude

    Port: China Port

    Lead Time : Around 40 days after payment


    Type3 Axles Van Semi Trailer
    Dimension
    Size12500*2500*1550mm
    Weight
    Payload30,000kg
    Tare weightApprox. 1,100kg
    G.V.W.RApprox. 41,000kg
    Frame&Structure
    Main beamMaterial Q345B,Fabricated”H”beam height 500mm,Top flange thickness 14mm,Middle web thickness 8mm,Bottom flange thickness 16mm
    Side beam16#channel steel
    Platform3mm thick chequer plate with supporting channel
    Stand columnStandard design with support to the frame body
    RoofSteel ,water proof design
    Cross beam80*40mm square tube
    KingpinJOST 2"SAE kingpin,bolted in type
    Welding standardAll welding are to be done by qualified welder per applicable national standard
    PaintingShot blast at standard SA2.5 prior to application of primer,polyurethane top coat. Total DFT not less than 100um
    Running gear
    Suspensionechanical suspension,leaf spring 13mm×90mm,China
    AxleFUWA150×150square beam axle,3pcs*13ton capacity,China
    Brake systemDuine pneumatic brake,SAE hose and connector
    Brake chamber4 units T30/30 spring brake chambers,2 units T30 brake chambers
    Air tank40L,2pcs,China
    Emergency relay valveShunanda relay valve
    TireDouble coin brand,12R22.5.12pcs, China
    Rim9.0*22.5 steel disc wheel,10 holes ISO,12pcs,China
    Landing gearStandard 28T two speed telescopic manual landing gear



    Company Information

    As a leading Chinese vehicle exporter, we have many years professional experience in this field.

    Besides the high quality of our vehicles, our international sales team will also provide you excellent logistics service and after-sales service.

    We will always do our best to solve all the problems and put our customer's interests in the first place.


    Our workshop

    Our factory has perfect inspection equipment and advanced inspection methods.owns inspection

    line and physic&chemical analysis rooms of special vehicle. large modern factory building of 3000

    square meters ,own advanced production line,painting line and technical equipment for special

    vehicles,and has annual design production capacity of 20000 vehicles.


    Our Services

    Pre-Sales Service

    The company has perfect inspection equipment and advanced inspection methods,owns inspection

    line and physic and chemicial analysis rooms of special vhicle,and makes over 200inspection items

    such as rear lower part protection,side protection,ABS braking and anti-skid brake system strictly

    according to national standards for special vehicles.

    After-Sales Service

    1).Training trailer operating and normal maintenance.

    2).Regularly call back to know the vehicle's working status.

    3).Supply the service of regular repair.

    4).The overaseas engineers are always ready to deal with unexpected needs.

    5).CKD and SKD are available.
