FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer

    Buy cheap FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer from wholesalers

    Buy cheap FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer from wholesalers
    • Buy cheap FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer from wholesalers
    • Buy cheap FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer from wholesalers
    • Buy cheap FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer from wholesalers
    • Buy cheap FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer from wholesalers

    FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer

    Ask Lasest Price
    Brand Name : Star Trailer
    Model Number : FT1-001
    Certification : ISO/CCC
    Price : Negotiable
    Payment Terms : L/C, T/T,
    Supply Ability : 300 Units per month
    Delivery Time : 40 days after down payment received
    • Product Details
    • Company Profile

    FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer

    FEA Analysis 40 Foot Flatbed Trailer , PRO - E Design Extendable Flatbed Trailer

    Overview

    Quick Details

    Use:Truck Trailer Type:Semi-Trailer Material:Carbon Steel

    Certification:CCC/ISO Size:12500x2500x3100mm OEM No.:WP240

    Max Payload:35T Place of Origin:Shandong, China (Mainland)

    Brand Name:Star Trailer Total Weight:39500kg

    Loading Capacity:25T~80T according to your requestment

    Axle Brand:BPW / FUWA Suspension System:Mechanical Suspension, Air Suspension,

    Wheel Rim:8.25*22.5/9.00*22.5 Zhengxing brand King Pin:JOST 2.0 inch (50mm)/3.5 inch (90mm)

    Landing Gear:JOST

    Twist Locks:4, 8, 12pieces (Lifting type or Twist Screw type), optional Customization:

    According to your request

    Feature:

    FEA Analysis,PRO-E Design,Stronger and Longer Service Life
    Supply Ability
    Supply Ability:

    300 Set/Sets per Month

    Packaging & Delivery

    Packaging Details

    "1.Nude Packing 3 sets stacked (by Bulk Cargo Ship, Ro-ro Ship, or Land Transportation) ;
    2. Cut the rear part which can load two sets in one 40ft container ;
    3. Keep the trailer original but load two sets in one 45ft container ."

    Port

    Qingdao, Tianjin, Shanghai, Or as request

    Star Trailer Focus on High Quality 2 Axles 40Ton Semi Truck Flatbed Trailer
    Vehicle UseMainly used for medium and long-distance transport of large cargo & contaienr transportation
    Dimensions12500x2500x3100mm
    Loading Capacity25T~80T according to your requestment
    FloorMaterial Q345B,
    Thickness 3mm,4mm,6mm diamond steel plate
    Main BeamQ345B/T700/BS960 Strong Main Beam,
    Height 500mm,
    Upper Thickness 14mm ~ 20mm,
    Middle Thickness 6mm ~ 12mm
    Down Thickness 16mm ~ 22mm
    Side BeamQ235 Channel Steel
    Axle Weight Load13T/16T/20T
    Axle BrandBPW / FUWA / Shandong local axle
    Suspension SystemMechanical Suspension, Air Suspension, Bogie Suspension
    Wheel Rim8.25*22.5/9.00*22.5
    Zhengxing brand
    Tire11.00R20, 12.00R20,12R22.5, 385/65R22.5
    Triangle, Chengshan, Doublestar, Linglong
    King PinJOST 2.0 inch (50mm)/3.5 inch (90mm)
    Landing GearJOST / FUWA 28T or according to your request
    Twist Locks4, 8, 12pieces (Lifting type or Twist Screw type), optional
    Brake SystemWABCO Valve with big chamber
    ABSCustomer optional
    LightsTurning Light, Side Marker Light, Tail Light
    Voltage24V
    Receptacle7 ways (7 wire harness)
    Tool BoxCustomer optional
    Spare Tire CarriersCustomer optional
    Painting ColorCommon China made Paint / Polyurethane paint, Color optional
    CustomizationAccording to your request
    Packing1.Nude Packing 3 sets stacked (by Bulk Cargo Ship, Ro-ro Ship, or Land Transportation) ;
    2. Cut the rear part which can load two sets in one 40ft container ;
    3. Keep the trailer original but load two sets in one 45ft container .
    Delivery Time15~25 days after deposit received.

    Delivery time:40 days after advance received Color:Any color

    Supply Abilty
    300 Set/Sets per Month

    Product Overviews:

    Manufacturing accessories:

    Lowbed semi-trailers are commonly used for transporting construction machineries such as bulldozers, excavators and overheight equipment such as transformer, generator, etc.

    Star Trailer design & manufactures best useful lowboy trailers and mobile workshop truck bodies to meet customer requirements with high standards.Star Trailer specializes in the production of special lowboy trailers like extendable, hyraulic and self steered semi low loaders, special design flatbed trailers that meets all driver needs, mobile workshop truck bodies for basic maintenance, tyre repair, pipe-line maintenance etc.


    Production packaging:

    Our Customers:

    Our advantages:

    1.High-grade steel for semi-trailer

    The steel we use is high-grade steel, it contains niobium and 0.98‰ of titanium, which keep the chassis very strong with great torsional stiffness and a low dead weight. The main beams are the strongest in the market, allowing for more load capacity. We are proud to offer every customer 5-year warranty on the mainframe.

    2.Designed for optimial load distribution


    Our trailer are designed for optimal load distribution. Instead of two web reinforcement structure design which is commonly use by other Chinese factories, we adopt the structure of width plate and stiffened plate reinforcement. As a result, our trailer has great torsional stiffness and is extremely stable when loaded.


    3.Weld quality


    In order to ensure the weld quality in the key parts of the trailer, we have introduced advanced welding machine in our production line, including submerged arc welding machine, welding robots, and kingpin welding machine, etc.
