    9.5 Meters 2 Axles Long Flatbed Trailer , Semi Truck Lightweight Flatbed Trailer

    Ask Lasest Price
    Brand Name : Star Trailer
    Model Number : FT1-004
    Certification : ISO/CCC
    Price : Negotiable
    Payment Terms : L/C, T/T,
    Supply Ability : 300 Units per month
    Delivery Time : 40 days after down payment received
    • Product Details
    • Company Profile

    9.5 Meters 2 Axles Long Flatbed Trailer , Semi Truck Lightweight Flatbed Trailer

    Overview

    Quick Details

    Use:Truck Trailer Type:Semi-Trailer Material:Steel

    Certification:ISO/CCC Size:13165x2550x1500mm OEM No.:low bed semi trailer

    Max Payload:80T Place of Origin:Shandong, China (Mainland)

    Brand Name:Star Trailer Axle:FUWA or BPW Tire:1100R20/12R22.5/315/80R22

    Suspension:Leaf Spring Suspension Landing Gear:JOST brand 2.0(50mm) or 3.5

    King pin:50# or 90# Color:Customers' Optional

    Function:Transport excavator and machine

    Delivery time:40 days after advance received Color:Any color

    Supply Abilty
    300 Set/Sets per Month

    Product Overviews:

    13 Meters Heavy Duty Flatbed Semi Trailer



    Product Description:

    Product parameters

    Item2 Axles flatbed semi trailer3 Axles flatbed container trailer
    Tare Weight6100kg7200kg
    Loading Capacity40-50T50-60T
    Axle Weight Load13T13T
    Specification:
    Axle number23
    Axle BrandFuwaFuwa
    SuspensionCommon mechanicalCommon mechanical
    King Pin2" or 3.5" traction pin2" or 3.5" traction pin
    Dimensions (LxWxH)12500×2500×1550mm12500×2500×1550mm
    Wheel Rim9.0-22.5 steel wheel rim9.0-22.5 steel wheel rim
    Steel Spring10 pieces per axle10 pieces per axle
    Twist lock12 sets twist lock for 1*20ft,2*20ft,1*40ft container
    Floor3mm diamond steel plate
    Landing Gear28T Manual operating, Heavy duty landing gear
    Accessories1 Set standard tool box1 Set standard tool box
    LightTail lamp with turn signal, brake light & reflector, side lamp etc.
    Painting1 coat of anticorrosive prime, twice coats of final paint
    Tire:
    Tire spec.12R22.5
    Number of Tire8 pieces12 pieces
    Spare Tire Carriers2 pieces2 pieces
    Frame: (specs. and materials)
    Main beam

    Q345 Steel

    The height of the beam is500mm;

    Upper plate:14mm;Down plate is 16mm;Middle plate is 8mm.

    Cross beam10# channel steel
    Side beam16# channel steel
    Brake:
    Brake Chamber4 big chamber6 big chamber
    Brake systemDual Line Brake system
    Packing and shipment

    3 axle heavy equipment trailer

    Packing details:Nude packing,small type can be put into 20"GP or 40"GP,big type can be carried by bulk on deck or ro-ro ship or according to your requirements.

    Delivery time:25 days after receiving the deposit

    roduction packaging:

    Our Customers:



    Our advantages:

    1.High-grade steel for semi-trailer

    The steel we use is high-grade steel, it contains niobium and 0.98‰ of titanium, which keep the chassis very strong with great torsional stiffness and a low dead weight. The main beams are the strongest in the market, allowing for more load capacity. We are proud to offer every customer 5-year warranty on the mainframe.

    2.Designed for optimial load distribution


    Our trailer are designed for optimal load distribution. Instead of two web reinforcement structure design which is commonly use by other Chinese factories, we adopt the structure of width plate and stiffened plate reinforcement. As a result, our trailer has great torsional stiffness and is extremely stable when loaded.


    3.Weld quality


    In order to ensure the weld quality in the key parts of the trailer, we have introduced advanced welding machine in our production line, including submerged arc welding machine, welding robots, and kingpin welding machine, etc.
