    3 Axles Container Skeletal Trailers 40ft Skeletal Chassis Use Transport

    Ask Lasest Price
    Brand Name : Startrailer
    Model Number : CC-007
    Certification : CCC、ISO
    Price : USD$8500~$13000
    Payment Terms : L/C, T/T
    Supply Ability : 100 units per month
    Delivery Time : 25 days after receive deposite
    • Product Details
    • Company Profile

    3 Axles Container Skeletal Trailers 40ft Skeletal Chassis Use Transport

    3 Axles Container Skeletal Trailers 40ft Skeletal Chassis Use Transport
    Overview
    Quick Details

    Use:Truck Trailer Type:Semi-Trailer, Truck Trailer
    Material:Steel Certification: SGS ISO CCC
    Size:20 40 45 53 Feet OEM No.:3708322800116
    Max Payload:45 - 100 Tons Place of Origin:Shandong, China (Mainland)
    Brand Name:Startrailer USAGE:CONTAINERS TRANSPORT Logo:By customer Needs Condition:New Made / Customize by needs
    Axle :FUWA/BPW13-20Tons Suspension:Bogie/Air/Mechanic/Rigid Optional
    Color:Customers Optional Tire:12R22.5
    King pin:2"(50mm)or3.5"(90mm) Landing Gear:Standard 28Ton

    Packaging & Delivery

    Selling Units:Signal
    Single package size:1200X250X158 cm
    Single gross weight:6500.0 kg
    Package Type:
    BY BULK/CONTAINER/RORO SHIP
    Lead Time :

    Quantity(Set)1 - 1>1
    Est. Time(days)20To be negotiated

    New Yellow 2 Axles 20ft Skeletal Used Semi 20 ft Skeleton Container Chassis Trailer


    Product Description
    Transport Skeleton Container Trailer
    Dimension(Optional)Axle No.Rated Load (kg)Tire No.Tire Size
    20ft2400008825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier)
    40ft 45ft 48ft 53ft36000012
    40ft 45ft 48ft 53ft47500016
    Wheel Base (mm)1310
    leaf-spring Pcs10
    Axle13/16/18 T
    SuspensionHeavy Duty Mechanic Suspension with Leaf Springs
    Main Beam MaterialQ345B manganese plates, automatic submerged arc welded
    Brake SystemDual line braking system with automatic braking system/chambers
    Brake Air ChamberDouble Model
    Kingpin2' or 3.5' Interchangeable
    Landing gearJOST E100
    PlatformSkeletal Chassis Loading Deck
    Brake SystemDual Lines Braking System With Automatic Air Chambers
    Brake Air ChamberFour double and two single chamber
    Electrical System24V, 7core socket, lights according to European standards.

    Mainbeam Size

    Upper plate14mm
    Lower plate16mm
    Mid Web8 mm
    Height500-520mm
    Tool Box1 box of standard tools
    Spare tire carrier2 sets
    Color and LogoDepends on the buyer’s requirement.
    Pin HeightAccording to the height of the tractor saddle.
    PaintingThree coats painting; Any color will be ok
    Other SpecificationsThe frame can be flat plate style and skeleton style.Twist lock settings installed 12pics, 8 pics, and 4pcs to satisfy the containers with different sizes for convince.
    ApplicationFor 2x20ft or 1x40ft containers transport

    Accessories

    The Star trailer fourth generation terminal trailer is using accessories per standard of DOT ( Department of Transportation of USA), which is meeting the requirement of different operating environments and prolong the service life. Star trailer products has been the choice of international ports from tropical country such as Singapore, to the extreme cold climate such as Vladivostok of Russia.


    Drawing
    This drawing is only for reference

    Factory environment
    Startrailer is the first semi-trailer manufacturer in China Committed to produce low maintenance long service life trailer for container ports. The company occupies an area of 80,000 square meters, with assets of 120 million yuan and more than 280 employees. It has an annual production capacity of 3,000 terminal trailers.
    With the harmonized team work of the management and staff member, we have successfully developed international customer base such as Singapore, South Korea, Australia, New Zealand, Russia, . . . . and established long-term cooperative relations.
    The factory is equipped with digital control laser and plasma cutting machine, laser beam guided submerged arc welding machine, welding robot, automatic punching machine, automatic welding and other equipment. While reducing the labor intensity of production workers and improving production efficiency, the quality of products is guaranteed.

    Shot blasting machine

    CNC plasma cutting machine CNC shearing machine

    FAQ
    What’s The Guarantee Period On Our Products ?
    - All Products We Export Has 1 Year Guarantee Period, And For The Beam Is Lifetime Promise. As Exporting Experience
    For Years, All Products From Our Factory Can Meet The Exporting Countrys Standards On Vehicles, All Vehicles Will Be
    Built Upon The Related Countries Road Condition, And Our Sales Manager Will Provide Customer The Best SuggestionsBefore Placing The Order. If Some Easy Weary Small Parts, We Can Offer Free In 6 Months.
